Dynajet Smart Droplet Management
By automatically controlling the pressure and drop size across a wide range of speeds, DynaJet allows you to choose optimal speeds while maintaining a consistent drop size everywhere in the field under even the most challenging conditions. Just program your drop size from the cab and go.
The DynaJet system is designed to optimize spraying applications in agriculture by maintaining consistent droplet size and spray quality s. Here are some key features:
- Automatic Control: DynaJet automatically adjusts pressure and droplet size, allowing you to maintain optimal speeds and consistent droplet size throughout the field
- Ease of Use: You can program the desired droplet size from the cab, simplifying the spraying process.
- Precision: The system ensures that droplet size remains constant, which is crucial for effective crop protection
- Efficiency: It reduces the need for multiple spray tips, covering a wider range of applications and improving productivity
- Environmental Protection: By reducing spray drift, DynaJet helps safeguard the environment.
The TeeJet DynaJet system significantly reduces spray drift, which is crucial for protecting the environment and ensuring precise application. Here are some key aspects of its drift reduction capabilities:
These features make the DynaJet system highly effective in minimizing spray drift, ensuring that the applied products reach their intended targets efficiently.
- Pulse Width Modulation (PWM) Technology: DynaJet uses PWM to control the spray nozzles, turning them on and off up to 20 times per second. This ensures consistent droplet size and reduces the likelihood of smaller droplets that can drift away.
- Drift Reduction Nozzles: The system is compatible with specific nozzles designed to minimize drift. These nozzles produce coarser droplets, which are less likely to be carried away by the wind.
- Real-Time Adjustments: DynaJet continuously adjusts pressure and droplet size in real-time, maintaining optimal conditions for reducing drift even as field conditions change.
- Environmental Protection: By reducing the number of fine droplets, DynaJet helps prevent the contamination of nearby areas, such as watercourses and non-target plants.
DYNAJET 7140 vs. DYNAJET IC7140
DynaJet offers two variations to achieve the optimal solution for your needs – DynaJet 7140 and DynaJet IC7140, an ISOBUS compatible system.
DynaJet® Nozzle Control System
SMART DROPLET MANAGEMENT
Control
Consistent drop size, spray quality
and performance require DynaJet.
The TeeJet DynaJet system is versatile and can be used in various agricultural applications to enhance spraying efficiency and effectiveness. Here are some specific applications:
- Crop Protection: Ensures consistent droplet size for effective pesticide and herbicide application, reducing the risk of under or over-application.
- Fertilizer Application: Optimizes the distribution of liquid fertilizers, ensuring even coverage and better nutrient absorption by crops.
- Disease Control: Helps in the precise application of fungicides, improving disease management in crops.
- Drift Reduction: Minimizes spray drift, protecting surrounding areas and non-target plants.
- Variable Rate Application: Allows for variable rate spraying, adjusting the amount of product applied based on field conditions and crop needs.
These applications help farmers achieve better crop yields, reduce waste, and protect the environment.
SIMPLICITY
Just select the droplet size required
for the product you are applying
and go.
PRECISION
Droplet size remains constant throughout the
entire application, ensuring optimal
crop protection.
COMFORT
Less stress. No more having to calculate droplet
size based on pressure and speed.
DynaJet does it for you!
EFFICIENCY
Use fewer spray tips to cover a wider
range of spraying applications, for
improved productivity.
FLEXIBILITY
Choose the best ground speed for your
application without having to
change sprayer settings.
SUSTAINABILITY
Spray the correct droplet size for field
conditions and reduce the risk of
drift.
